How can you safeguard steel mounting frames against wind to ensure stability?

Galvanised and galvalume steel are popular options for constructing solar panel frames due to their durability, strength and resistance to corrosion. Galvanised steel has a protective zinc coating, while galvalume steel is coated with a zinc-aluminium alloy, providing excellent protection against rust and corrosion. This makes them ideal for outdoor applications such as solar panels exposed to various weather conditions throughout their lifetime.

Safeguarding steel mounting frames against wind is essential for these reasons

• Structural integrity: wind can exert significant forces on solar panel installations, especially in areas prone to high winds or gusts. The mounting frames could only succeed with proper reinforcement and anchoring, leading to structural damage or collapse.

• Protection of solar panels: the mounting frames support the solar panels, so ensuring their stability helps protect the panels themselves. If the frames fail due to wind, it could damage the panels, reducing their efficiency or rendering them inoperable.

• Safety: a failure of the mounting frames due to wind could pose safety hazards to nearby structures, people, or property. Properly secured frames minimise the risk of accidents or injuries caused by falling panels or structures.

• Longevity of the installation: by safeguarding against the wind, the mounting frames can maintain their structural integrity over time, prolonging the lifespan of the entire solar panel system. This ensures that the investment in renewable energy remains viable and continues to provide benefits over the long term.


Solar steel frames fabricated from steel undergo the following steps

• Material selection: high-quality galvanised or galvalume steel coils are chosen as the starting material. These coils are typically sourced from steel manufacturers and suppliers.

• Cutting: the steel coils are uncoiled and then cut into the required lengths and widths using shearing machines or laser cutting equipment. Precise measurements are essential to ensure consistency and accuracy in the fabrication process.

• Punching and drilling: holes for bolts, fasteners, and other assembly components are punched or drilled into the steel pieces. This step is critical for attaching the frames to support structures and mounting the solar panels later.

• Bending and forming: hydraulic or mechanical presses bend and form the steel pieces into the desired shapes and angles for the solar panel frames. This step involves careful manipulation of the steel to achieve the required structural integrity and dimensional accuracy.

• Welding: in some cases, welding is used to join multiple steel components, especially for larger or more complex frame structures. Welding ensures solid and durable connections between the frame elements.

• Surface treatment: after fabrication, the steel frames may undergo additional surface treatments to enhance their corrosion resistance and durability. This could include applying protective coatings or treatments to safeguard the frames against environmental factors further.


Design considerations to ensure wind resistance

• Calculate wind loads: determine wind pressure and other factors based on local data and building codes to find the loads on the structure.

• Select structure and layout: choose a sturdy structural form like frame-supported or cylinder structures. Arrange components to distribute stress evenly and avoid weak points.

• Design components and nodes: size components to handle wind loads. Focus on crucial nodes like steel beam and steel column connections, ensuring they're strong and secure.

• Structural analysis: conduct a structural analysis to determine the forces acting on the mounting frame due to wind loads. This analysis should consider factors such as wind directionality, gust effects, and the dynamic response of the structure.

• Anchoring: properly anchor the mounting frame to the foundation or supporting structure. The anchoring system should be designed to withstand the anticipated wind loads and prevent overturning or uplift.

• Address wind vibration: account for wind-induced vibration, especially in tall or flexible structures. Use dampers and other measures to mitigate vibration effects.

• Incorporate windproof features: enhance wind resistance with strategies like windbreaks and roof steel plates to reduce wind impact.


Protecting steel mounting frames against wind is crucial for ensuring solar panel installations' stability, safety, and longevity. Proper design, engineering, and installation techniques are essential to mitigate the risks associated with wind loading and ensure system reliability.
