Factors to consider when making nails and screws made from wire rods

IS 7887:1992 SAE1008, SAE1018 and SAE1006 wire rods are low-carbon and highly versatile. IS 7887:1992 is an Indian Standard specification for hot-rolled steel wire rods for general engineering purposes. SAE stands for Society of Automotive Engineers. These are American standard steel grades designated by the SAE-AISI system. These wires are used in the manufacturing of nails, screws, wire mesh, wire ropes, and other wire-based items. They are known for their excellent surface finish, which makes them suitable for applications where appearance is essential. They offer excellent formability, drawability, and weldability and are widely used. These rods have excellent corrosion resistance and are highly durable. They are commonly treated using wire drawing processes to produce different wires.

Factors to consider when wire rod drawing to make fasteners

• Material selection: the choice of material for the wire rods is crucial. Common materials include carbon steel and various alloys. Each material has different properties, such as strength, corrosion resistance, upsettability (a measure of the ductility) and cost, which should be considered based on the intended application.

• Wire diameter: the diameter of the wire rods determines the size of the nails or screws produced. It's essential to select the appropriate diameter based on the desired strength and functionality of the fastener.

• Wire quality: the quality of the wire rods directly affects the quality of the nails and screws. Factors such as tensile strength, surface finish, upsettability (a measure of the ductility) and uniformity of the wire should be considered to ensure consistent performance and durability.

• Manufacturing process: various manufacturing processes can be used to fabricate nails and screws from wire rods like cold heading (a length of wire is inserted into a die and then struck with a punch at high speed and pressure), thread rolling (produces threads on cylindrical parts such as bolts, screws, etc.), and heat treatment. The choice of process depends on factors such as the fasteners' desired shape, size, and properties.

• Surface treatment: surface treatment, such as galvanising or coating, can enhance the corrosion resistance and appearance of the nails and screws. The appropriate surface treatment should be selected based on the environmental conditions and the intended use of the fasteners.

• Quality control: rigorous quality control measures should be implemented throughout the fabrication process to ensure that the nails and screws meet the required specifications and standards. This includes monitoring dimensional accuracy, mechanical properties, and surface finish.

Key performance indicators

Tensile Strength measures the maximum stress a material can withstand while being stretched or pulled before breaking. For steel wire rods like SAE1008, SAE1018, and SAE1006, typical tensile strengths can vary based on processing, heat treatment, and alloying elements. However, these grades generally exhibit tensile strengths within a specific range. For example:

• SAE1008: Typically has a tensile strength ranging from 340 MPa to 420 MPa.

• SAE1018: Typically has a tensile strength ranging from 440 MPa to 540 MPa.

• SAE1006: Typically has a tensile strength ranging from 290 MPa to 380 MPa.

Durability refers to the ability of a material to withstand various environmental and mechanical stresses over time without degradation. Steel wire rods like SAE1008, SAE1018, and SAE1006 are known for their durability, making them suitable for various applications.

Fasteners manufactured from low-carbon wire rods play a pivotal role across diverse industries due to their fundamental importance in assembly and construction applications. The chemical composition of low-carbon steel wire rods provides excellent weldability, making it easy to connect through various welding techniques and robust joints. These components, like bolts, screws, nails, and rivets, serve as the backbone for joining materials in the automotive, aerospace, construction, manufacturing, and electronics sectors.
